Printer Status Sensors

Zebra XiII-Series printer contains several status sensors. These sensors alert
the operator to various conditions by either stopping the printing or turning
on a light. Sensors are described in Table 3.

Table 3. Printer Status Sensors

Sensor

What It Monitors

How It Works

Printhead

Position Sensor

Checks the open/closed

status of the printhead

lever.

If the printhead is open, the Error light flashes.

Printhead

Temperature

Sensor

Checks the temperature

of the printhead.

If the printhead is too cold, the front panel

display indicates this condition and printing

continues while the printhead warms up. If the

printhead is too hot, printing stops while the

printhead cools to standard operating

temperature.

Transmissive

Media Sensor

Checks for proper media

loading.

The Paper Out light will turn on if you run out

of media. This condition will also occur if you

are using non-continuous media and the media

does not move because it is jammed.

If non-continuous media

is used, this sensor

detects the label length

for individual labels.

Reflective

Media Sensor

Detects the presence of

black marks on the back

of black-mark media.

If it detects a black mark, the printer knows that

it is at the beginning of a label.

Ribbon Sensor Monitors the presence of

ribbon.

If you run out of ribbon, the Check Ribbon light

turns on.

Label Available

Sensor

In Peel-Off Mode, it

checks to see if a label is

available.

Once a label prints, it will pass between the

two parts of this sensor and cause the printer

to pause. The Take Label light turns on. When

the label is removed, printing resumes and the

light turns off.

Zebra XiII-Series User’s Guide

27
