Zebra Technologies XiII-Series User Manual
Page 11

List of Figures
1. Media Loading
8
2. Roll Media Loading
9
3. Fanfold Media Loading
10
4. Upper Media Sensor Adjustment
16
5. Lower Media Sensor Adjustment
17
6. Ribbon Loading Diagram for the 90XiII and 140XiII Printers
19
7. Ribbon Loading Diagram for the 170XiII and 220XiII Printers
19
8. Removing Used Ribbon
20
9. Front Panel
24
10. Media and Ribbon Sensor Profile Sample Printout
46
11. Cleaning Diagram
53
12. Fuse Replacement Step 1
55
13. Fuse Replacement Step 2
55
14. Toggle Adjustment
56
15. Cancel Key Self Test Sample Printout
66
16. Pause Key Self Test Sample Printout
67
17. Feed Key Test Sample Printout
69
18. Communications Diagnostics Test Sample Printout
69
19. Power Line Cord
82
20. International Safety Organizations
82
21. Standard Printer Font Examples
84
22. Select Examples of Optional Fonts
86
23. Bitmap Smooth Fonts: Point Size Examples
86
24. RS-232 Connections
89
25. 9 Pin to 25 Pin Interconnecting Cable
90
26. 25 Pin to 25 Pin Interconnecting Cable
90
27. RS-422/RS-485 Interconnecting Cable
91
28. RS-422/RS-485 Connections
91
29. Bar Code Examples
97
Zebra
XiII-Series User’s Guide
xi
11
