GS-3012/GS-3012F User’s Guide
Basic Setting 6-11
Table 6-4 IP Setup
LABEL DESCRIPTION
IP Subnet
Mask
Enter the IP subnet mask in dotted decimal notation.
VID Type the VLAN group identification number.
Default
Gateway
Enter the IP address of the default outgoing gateway in dotted decimal notation.
Add Click Add to save the new rule to the switch. It then displays in the summary table at the bottom of
the screen.
Cancel Click Cancel to reset the fields to your previous configuration.
Index This field displays the index number of the rule. Click an index number to edit the rule.
IP Address This field displays the IP address.
IP Subnet
Mask
This field displays the subnet mask.
VID This field displays the ID number of the VLAN group.
Default
Gateway This field displays the IP address of the default gateway.
Delete Check the rule(s) that you want to remove in the Delete column, then click the Delete button.
Cancel Click Cancel to clear the selected checkboxes in the Delete column.
6.7 Port Setup
Click Basic Setting and then Port Setup in the navigation panel to enter the port configuration screen.
