GS-3012/GS-3012F User’s Guide
3-8 Hardware Connections
Table 3-2 Front Panel LED Descriptions
LED COLOR STATUS DESCRIPTION
ALM Red On There is a hardware failure.
Off The system is functioning normally.
Mini GBIC Slots
LNK Green On The link to this port is up.
Off The link to this port is not connected.
ACT Green Blinking This port is receiving or transmitting data.
Gigabit Ports
LNK/ACT Green Blinking The system is transmitting/receiving to/from an Ethernet network.
(GS-3012) On The link to a 1000 Mbps Ethernet network is up.
Off The link to an Ethernet network is down.
Amber Blinking The system is transmitting/receiving to/from an Ethernet network.
On The link to a 100 Mbps Ethernet network is up.
Off The link to an Ethernet network is down.
FDX (GS-3012) Amber On The Gigabit port is negotiating in full-duplex mode.
Off The Gigabit port is negotiating in half-duplex mode and no collisions are
occurring.
1000 (GS-
3012F)
Green Blinking The system is transmitting/receiving to/from an Ethernet network.
On The link to a 1000 Mbps Ethernet network is up.
Off The link to a 1000 Mbps Ethernet network is down.
100 (GS-3012F) Amber Blinking The system is transmitting/receiving to/from an Ethernet network.
On The link to a 100 Mbps Ethernet network is up.
Off The link to a 100 Mbps Ethernet network is down.
MGMT
10 Green Blinking The system is transmitting/receiving to/from an Ethernet device.
On The port is connected at 10Mbps.
Off The port is not connected at 10Mbps or to an Ethernet device.
100 Amber Blinking The system is transmitting/receiving to/from an Ethernet device.
On The port is connected at 100Mbps.
Off The port is not connected at 100Mbps or to an Ethernet device.
3.5 Configuring the Switch
You may use the embedded web configurator or command line interface to configure the switch. If you’re using the
web configurator, you need Internet Explorer 5.5 and later or Netscape Navigator 6 and later.
