GS-3012/GS-3012F User’s Guide
Multicast 20-7
will still be on the list of forwarding destination for the multicast traffic. Otherwise, the switch removes the receiver
port from the forwarding table.
Figure 20-5 MVR Multicast Television Example
20.6 General MVR Configuration
Use the MVR screen to create multicast VLANs and select the receiver port(s) and a source port for each multicast
VLAN. Click Advanced Applications and Multicast in the navigation panel. Click the Multicast Setting link and
then the MVR link to display the screen as shown next.
You can create up to three multicast VLANs and up to 256 multicast rules on the switch.
Your switch automatically creates a static VLAN (with the same VID) when you create a multicast
VLAN in this screen.
