GS-3012/GS-3012F User’s Guide
4-4 Introducing the Web Configurator
Table 4-2 Web Configurator Screen Sub-links Details
BASIC SETTING ADVANCED APPLICATION IP APPLICATION MANAGEMENT
Port Authentication
RADIUS
802.1x
Port Security
Queuing Method
Classifier
Policy Rule
Multicast
Multicast Status
Multicast Setting
IGMP Filtering Profile
MVR
Status
Cluster Management
Configuration
MAC Table
ARP Table
The following table summarizes these sub-links in the navigation panel.
Table 4-3 Navigation Panel Sub-link Descriptions
LABEL DESCRIPTION
Basic Setting Screens
System Info This link takes you to a screen that displays general system and hardware monitoring
information.
General Setup This link takes you to a screen where you can configure general identification information
about the switch.
Switch Setup This link takes you to a screen where you can set up global switch parameters such as
VLAN type, MAC address learning, IGMP snooping, GARP and priority queues.
IP Setup This link takes you to a screen where you can configure the IP address, subnet mask
(necessary for switch management) and DNS (domain name server).
Port Setup This link takes you to screens where you can configure settings for individual switch ports.
Advanced Application
VLAN This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding This link takes you to screens where you can configure static MAC addresses for a port.
These static MAC addresses do not age out.
Filtering This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the STP to prevent network loops.
Bandwidth Control This link takes you to screens where you can define a maximum allowable bandwidth for
incoming and/or out-going traffic flows on a port.
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
