Table 5-9. Megamodule L1/L2 Memory Protection Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0184 AD08 L1DMPLK2 L1D memory protection lock key bits [95:64]
0184 AD0C L1DMPLK3 L1D memory protection lock key bits [127:96]
0184 AD10 L1DMPLKCMD L1D memory protection lock key command register
0184 AD14 L1DMPLKSTAT L1D memory protection lock key status register
0184 AD18 - 0185 FFFF - Reserved
Table 5-10. CPU Megamodule Bandwidth Management Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0182 0200 EMCCPUARBE EMC CPU Arbitration Control Register
0182 0204 EMCIDMAARBE EMC IDMA Arbitration Control Register
0182 0208 EMCSDMAARBE EMC Slave DMA Arbitration Control Register
0182 020C EMCMDMAARBE EMC Master DMA Arbitration Control Resgiter
0182 0210 - 0182 02FF - Reserved
0184 1000 L2DCPUARBU L2D CPU Arbitration Control Register
0184 1004 L2DIDMAARBU L2D IDMA Arbitration Control Register
0184 1008 L2DSDMAARBU L2D Slave DMA Arbitration Control Register
0184 100C L2DUCARBU L2D User Coherence Arbitration Control Resgiter
0184 1010 - 0184 103F - Reserved
0184 1040 L1DCPUARBD L1D CPU Arbitration Control Register
0184 1044 L1DIDMAARBD L1D IDMA Arbitration Control Register
0184 1048 L1DSDMAARBD L1D Slave DMA Arbitration Control Register
0184 104C L1DUCARBD L1D User Coherence Arbitration Control Resgiter
Table 5-11. Device Configuration Registers (Chip-Level Registers)
HEX ADDRESS RANGE ACRONYM REGISTER NAME COMMENTS
Read-only. Provides status of the
02A8 0000 DEVSTAT Device Status Register
user's device configuration on reset.
02A8 0004 PRI_ALLOC Priority Allocation Register Sets priority for Master peripherals
JTAG and BSDL Identification Read-only. Provides 32-bit JTAG ID of
02A8 0008 JTAGID
Register the device.
02A8 000C - 02AB FFFF - Reserved
02AC 0000 - Reserved
02AC 0004 PERLOCK Peripheral Lock Register
02AC 0008 PERCFG0 Peripheral Configuration Register 0
02AC 000C - Reserved
02AC 0010 - Reserved
02AC 0014 PERSTAT0 Peripheral Status Register 0
02AC 0018 PERSTAT1 Peripheral Status Register 1
02AC 001C - 02AC 001F - Reserved
02AC 0020 EMACCFG EMAC Configuration Register
02AC 0024 - 02AC 002B - Reserved
02AC 002C PERCFG1 Peripheral Configuration Register 1
02AC 0030 - 02AC 0053 - Reserved
02AC 0054 EMUBUFPD Emulator Buffer Powerdown Register
02AC 0058 - Reserved
