GMTCLK
(Output)
2
3
1
4
4
MRCLK (Input)
1
2
MRXD7−MRXD4(GMII only),
MRXD3−MRXD0,
MRXDV, MRXER (Inputs)
TMS320C6454
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
Table 7-77. Switching Characteristics Over Recommended Operating Conditions for GMTCLK - GMII
Operation (see
)
-720
-850
-1000
NO.
UNIT
1000 Mbps
MIN
MAX
1
t
c(GMTCLK)
Cycle time, GMTCLK
8
ns
2
t
w(GMTCLKH)
Pulse duration, GMTCLK high
2.8
ns
3
t
w(GMTCLKL)
Pulse duration, GMTCLK low
2.8
ns
4
t
t(GMTCLK)
Transition time, GMTCLK
1
ns
Figure 7-61. GMTCLK Timing (EMAC – Transmit) [GMII Operation]
Table 7-78. Timing Requirements for EMAC MII and GMII Receive 10/100/1000 Mbit/s
(1)
(see
-720
-850
-1000
NO.
UNIT
1000 Mbps
100/10 Mbps
MIN
MAX
MIN
MAX
Setup time, receive selected signals valid before
1
t
su(MRXD-MRCLKH)
2
8
ns
MRCLK high
Hold time, receive selected signals valid after
2
t
h(MRCLKH-MRXD)
0
8
ns
MRCLK high
(1)
For MII, Receive selected signals include: MRXD[3:0], MRXDV, and MRXER. For GMII, Receive selected signals include: MRXD[7:0],
MRXDV, and MRXER.
Figure 7-62. EMAC Receive Interface Timing [MII and GMII Operation]
