TMS320C6454
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
Table 2-3. Terminal Functions (continued)
SIGNAL
TYPE (1) IPD/IPU (2) DESCRIPTION
NAME NO.
RSV17 AE21 A
RSV18 E13 A
RSV19 F18 A
RSV20 U29 A
RSV21 A6 A
RSV22 B26 O
RSV23 C26 O
RSV24 B6 O
RSV25 C6 O
RSV26 AJ11 A
RSV27 AH11 A
RSV36 AD11 I/O/Z IPU
RSV37 AD9 I/O/Z IPU
RSV38 AG10 I/O/Z IPU
RSV39 AG11 I/O/Z IPU
RSV40 AJ12 I/O/Z IPU
RSV41 W28 O/Z IPU
RSV42 Y26 O/Z IPU
RSV43 Y25 O/Z IPU
Reserved. (Leave unconnected, do not connect to power or ground.)
RSV44 Y27 O/Z
RSV45 AF15 I
RSV46 AG15 I
RSV47 AF17 O/Z
RSV48 AG18 O/Z
RSV49 AG22 O/Z
RSV50 AF23 O/Z
RSV51 AF18 O/Z
RSV52 AG19 O/Z
RSV53 AG21 O/Z
RSV54 AF22 O/Z
RSV55 AH18 I
RSV56 AJ18 I
RSV57 AJ22 I
RSV58 AH22 I
RSV59 AH17 I
RSV60 AJ19 I
RSV61 AJ21 I
RSV62 AH23 I
RSV28 N7 A
RSV29 N6 A Reserved. These pins must be connected directly to V
SS
for proper device
operation.
RSV30 P23 A
RSV31 P24 A
Reserved. This pin must be connected to the 1.8-V I/O supply (DV
DD18
) via a
RSV32 D25
1-k
Ω
resistor for proper device operation.
Reserved. This pin must be connected directly to ground for proper device
RSV33 C25
operation.
