Product preview – Texas Instruments TMS320C6454 User Manual
Page 46
www.ti.com
PRODUCT PREVIEW
TMS320C6454
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
Table 2-3. Terminal Functions (continued)
SIGNAL
TYPE
(1)
IPD/IPU
(2)
DESCRIPTION
NAME
NO.
AC20
AC22
AC24
AC28
AD6
AD13
AD15
AD17
AD19
AD21
AD23
AE4
AE7
AE16
AE18
AE20
AE22
AE24
V
SS
GND
Ground pins
AF2
AF19
AF21
AG13
AG16
AG20
AG24
AH1
AH15
AH19
AH21
AH25
AH29
AJ8
AJ14
AJ16
AJ20
AJ24
Device Overview
46
