TMS320C6454
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
Table 7-4. EDMA3 Channel Controller Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A0 0300 EMR Event Missed Register
02A0 0304 EMRH Event MissedRegister High
02A0 0308 EMCR Event Missed Clear Register
02A0 030C EMCRH Event Missed Clear Register High
02A0 0310 QEMR QDMA Event Missed Register
02A0 0314 QEMCR QDMA Event Missed Clear Register
02A0 0318 CCERR EDMA3CC Error Register
02A0 031C CCERRCLR EDMA3CC Error Clear Register
02A0 0320 EEVAL Error Evaluate Register
02A0 0324 - 02A0 033C - Reserved
02A0 0340 DRAE0 DMA Region Access Enable Register for Region 0
02A0 0344 DRAEH0 DMA Region Access Enable Register High for Region 0
02A0 0348 DRAE1 DMA Region Access Enable Register for Region 1
02A0 034C DRAEH1 DMA Region Access Enable Register High for Region 1
02A0 0350 DRAE2 DMA Region Access Enable Register for Region 2
02A0 0354 DRAEH2 DMA Region Access Enable Register High for Region 2
02A0 0358 DRAE3 DMA Region Access Enable Register for Region 3
02A0 035C DRAEH3 DMA Region Access Enable Register High for Region 3
02A0 0360 DRAE4 DMA Region Access Enable Register for Region 4
02A0 0364 DRAEH4 DMA Region Access Enable Register High for Region 4
02A0 0368 DRAE5 DMA Region Access Enable Register for Region 5
02A0 036C DRAEH5 DMA Region Access Enable Register High for Region 5
02A0 0370 DRAE6 DMA Region Access Enable Register for Region 6
02A0 0374 DRAEH6 DMA Region Access Enable Register High for Region 6
02A0 0378 DRAE7 DMA Region Access Enable Register for Region 7
02A0 037C DRAEH7 DMA Region Access Enable Register High for Region 7
02A0 0380 QRAE0 QDMA Region Access Enable Register for Region 0
02A0 0384 QRAE1 QDMA Region Access Enable Register for Region 1
02A0 0388 QRAE2 QDMA Region Access Enable Register for Region 2
02A0 038C QRAE3 QDMA Region Access Enable Register for Region 3
02A0 0390 - 02A0 039C - Reserved
02A0 0400 Q0E0 Event Queue 0 Entry Register 0
02A0 0404 Q0E1 Event Queue 0 Entry Register 1
02A0 0408 Q0E2 Event Queue 0 Entry Register 2
02A0 040C Q0E3 Event Queue 0 Entry Register 3
02A0 0410 Q0E4 Event Queue 0 Entry Register 4
02A0 0414 Q0E5 Event Queue 0 Entry Register 5
02A0 0418 Q0E6 Event Queue 0 Entry Register 6
02A0 041C Q0E7 Event Queue 0 Entry Register 7
02A0 0420 Q0E8 Event Queue 0 Entry Register 8
02A0 0424 Q0E9 Event Queue 0 Entry Register 9
02A0 0428 Q0E10 Event Queue 0 Entry Register 10
02A0 042C Q0E11 Event Queue 0 Entry Register 11
02A0 0430 Q0E12 Event Queue 0 Entry Register 12
02A0 0434 Q0E13 Event Queue 0 Entry Register 13
02A0 0438 Q0E14 Event Queue 0 Entry Register 14
02A0 043C Q0E15 Event Queue 0 Entry Register 15
C64x+ Peripheral Information and Electrical Specifications 102 Submit Documentation Feedback
