7.11.2 I2C Peripheral Register Description(s)
TMS320C6454
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
Table 7-51. I2C Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02B0 4000 ICOAR I2C own address register
02B0 4004 ICIMR I2C interrupt mask/status register
02B0 4008 ICSTR I2C interrupt status register
02B0 400C ICCLKL I2C clock low-time divider register
02B0 4010 ICCLKH I2C clock high-time divider register
02B0 4014 ICCNT I2C data count register
02B0 4018 ICDRR I2C data receive register
02B0 401C ICSAR I2C slave address register
02B0 4020 ICDXR I2C data transmit register
02B0 4024 ICMDR I2C mode register
02B0 4028 ICIVR I2C interrupt vector register
02B0 402C ICEMDR I2C extended mode register
02B0 4030 ICPSC I2C prescaler register
02B0 4034 ICPID1 I2C peripheral identification register 1 [Value: 0x0000 0105]
02B0 4038 ICPID2 I2C peripheral identification register 2 [Value: 0x0000 0005]
02B0 403C - 02B0 405C - Reserved
02B0 4060 - 02B3 407F - Reserved
02B0 4080 - 02B3 FFFF - Reserved
