TMS320C6454
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
Table 7-4. EDMA3 Channel Controller Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A0 105C IECRH Interrupt Enable Clear High Register
02A0 1060 IESR Interrupt Enable Set Register
02A0 1064 IESRH Interrupt Enable Set High Register
02A0 1068 IPR Interrupt Pending Register
02A0 106C IPRH Interrupt Pending High Register
02A0 1070 ICR Interrupt Clear Register
02A0 1074 ICRH Interrupt Clear High Register
02A0 1078 IEVAL Interrupt Evaluate Register
02A0 107C - Reserved
02A0 1080 QER QDMA Event Register
02A0 1084 QEER QDMA Event Enable Register
02A0 1088 QEECR QDMA Event Enable Clear Register
02A0 108C QEESR QDMA Event Enable Set Register
02A0 1090 QSER QDMA Secondary Event Register
02A0 1094 QSECR QDMA Secondary Event Clear Register
02A0 1098 - 02A0 1FFF - Reserved
02A0 2000 - 02A0 2097 - Shadow Region 0 Channel Registers
02A0 2098 - 02A0 21FF - Reserved
02A0 2200 - 02A0 2297 - Shadow Region 1 Channel Registers
02A0 2298 - 02A0 23FF - Reserved
02A0 2400 - 02A0 2497 - Shadow Region 2 Channel Registers
02A0 2498 - 02A0 25FF - Reserved
02A0 2600 - 02A0 2697 - Shadow Region 3 Channel Registers
02A0 2698 - 02A0 27FF - Reserved
02A0 2800 - 02A0 2897 - Shadow Region 4 Channel Registers
02A0 2898 - 02A0 29FF - Reserved
02A0 2A00 - 02A0 2A97 - Shadow Region 5 Channel Registers
02A0 2A98 - 02A0 2BFF - Reserved
02A0 2C00 - 02A0 2C97 - Shadow Region 6 Channel Registers
02A0 2C98 - 02A0 2DFF - Reserved
02A0 2E00 - 02A0 2E97 - Shadow Region 7 Channel Registers
02A0 2E98 - 02A0 2FFF - Reserved
Table 7-5. EDMA3 Parameter RAM
(1)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A0 4000 - 02A0 401F - Parameter Set 0
02A0 4020 - 02A0 403F - Parameter Set 1
02A0 4040 - 02A0 405F - Parameter Set 2
02A0 4060 - 02A0 407F - Parameter Set 3
02A0 4080 - 02A0 409F - Parameter Set 4
02A0 40A0 - 02A0 40BF - Parameter Set 5
02A0 40C0 - 02A0 40DF - Parameter Set 6
02A0 40E0 - 02A0 40FF - Parameter Set 7
02A0 4100 - 02A0 411F - Parameter Set 8
02A0 4120 - 02A0 413F - Parameter Set 9
(1) The C6454 device has 256 EDMA3 parameter sets total. Each parameter set can be used as a DMA entry, a QDMA entry, or a link
entry.
Submit Documentation Feedback C64x+ Peripheral Information and Electrical Specifications 105
