Configuring Your System 3-19

SCSI Hard Disk Drives

Your Configuration

Descriptions

Recommended Settings or
Display Only

0

1

2

3

4

5

Device Selections

Press Enter for menu. Select
device and press Enter.

Sync Rate

40

Width (bits)

16

Disconnect

On

Read/Write I/O
timeout (sec)

10

Scan for device at
boot time

Yes

Scan for SCSI
LUNS

No

Queue Tags

On

SCSI Removable Media Devices

Your Configuration

Descriptions

Recommended Settings or
Display Only

Dev 0

Dev 1

Dev 2

Dev 3

Device Selections

Press Enter for menu. Select
device and press Enter.

Sync Rate

10

Width (bits)

8

Disconnect

On

Read/Write I/O
timeout (sec)

10

Scan for device at
boot time

Yes

Scan for SCSI
LUNS

No

Queue Tags

On

3.

Highlight the function you want to change and press

Enter

. You are

prompted to save changes when you exit the configuration utility.

Note:

If you wish to format a disk or verify disk media,

select “Format” or “Verify” from the Device Setup menu.
