Bezel Frame

Rectangular Cutout

Chassis Handle

Screws

Attaching the Chassis Handles

Attaching the Outer Slide Bars to the Chassis

Note:

If you have a rack unit, you must use the

following procedure to attach the slide bars before mounting
the unit in the rack. Observe all safety precautions,
warnings, and cautions noted throughout this chapter.

Each slide assembly consists of a large outer bar, a center bar, and a small outer
bar. The large outer bar and the center bar attach to the rack unit. The small
outer bar attaches to the system chassis. As the slide assembly ships as an
assembled unit, you must remove the small outer bar from the assembly before
attaching to the chassis.

Remove the small outer bar from each slide assembly and attach each bar to the
chassis as follows.

Position the slide assembly on a flat surface with the small outer bar down.

Fully extend the three telescoping bars until they lock in place (see the
following figure).
