Circuit Card Description and Installation
Connector pin assignments
Table 268 shows the pin assignments for J1 and J2 when the port is
configured for RS-232-C interface, and Table 269 on
page 860 shows the pin
assignments for J1 and J2 when the port is configured for the high-speed
interface.
Table 268
Connector J1 and J2 pin assignments – RS-232-C interface (Part 1 of 2)
Pin number Signal functions
Signal source
EIA
circuit To DCE From DCE
Ground and
common return
1 Shielded n/a n/a
7 Signal ground (SG) n/a n/a AB
Data
2 Transmitted data (TX) 3 — BA
3 Received data (RX) — 3 BB
Control
4 Request to send (RTS) 3 — CA
5 Clear to send (CTS) — 3 CB
6 Data set ready (DSR) — 3 CC
8 Carrier detect (CD) — 3 CF
20 Data terminal ready (DTR) 3 — CD
Timing
15 Transmitter signal element timing (DCE) — 3 DB
Note: Pins not used are 9 to 14, 16, 18, 19, 21, 22, 25.
