NT5D97 Dual-port DTI2/PRI2 card

553-3001-211 Standard 3.00 August 2005

Functional description

NT5D97 circuit card locations

Each NT5D97 card requires one slot on a shelf. NT5D97 cards can be placed
in any card slot in the network bus.

Note in all cases - If an NT8D72BA/NTCK43 card is being replaced by a
DDP2 card, the D-channel Handler can be reconnected to the DDP2 card, or
removed if an onboard NTBK51DDCH card is used. Also, DIP Switches in
the NT5D97 must be set properly before insertion. NT5D97 has a different
DIP Switch setting from NTCK43AB. Refer to “NT5D97AA/AB DIP switch
settings” on

page 340

for DIP switch setting).

NT5D97AA/AB DIP switch settings

The the NT5D97 DDP2 card is equipped with 6x2 sets of DIP switches for
trunk parameters settings for port0 and port1 respectively. Additionally, the
DDP2 card is equipped with one set of four DIP switches for the Ring Ground
setting. The NT5D97AA/AB has one set of eight DIP switches and
NT5D97AD has two sets of ten DIP switches for the D-channel Handler
parameters setting.

The DIP switches are used for the setting of default values of certain
parameters. Firmware reads the general purpose switches, which sets the
default values accordingly.

Table 121
DIP switch settings for NT5D97AA/AB (Part 1 of 2)

Card

Trunks
0 and 1

Port 0

Port 1

Trunk 0

Trunk 1

ENB/DSB
mounted on the face plate

S1

Ring Ground

S2

MSDL

S3

TX Mode

S4

S10
