Circuit Card Description and Installation
Throughout this document, if neither ON nor OFF is given (there is a blank
space) for a position on a switch, that position may be set to either ON or OFF
because it has no function for the option described.
Figure 17
Circuit card grid
S4
(switch 4
at coordinate
B11)
S8
(switch 8
at coordinate
F30)
ON
553-5491
33
37
35
31
29
27
25
23
21
19
17
15
13
11
9
7
5
A B C D E F G
ON
Positions
1 2 3 4 5 6 7 8 9 10
