Option settings Page 111 of 906
Circuit Card Description and Installation
Illustrations of switch locations and settings
Figure 18 on page 112 displays functional areas for switches on the
NT5D12AA DDP card.
9 on off off on
10 off on off on
11 on on off on
12 off off on on
13 on off on on
14 off on on on
15 on on on on
Note 1: The maximum number of DCHI, MSDL, and DDCH devices in the system is 16.
The Device Addresses are equivalent to the MSDL DNUM designations. For programming information on
the MSDL, refer to NTP Software Input/Output: Administration (553-3001-311) guide.
Note 2: Device address 0 is commonly assigned to the System Monitor.
Table 21
NTBK51AA daughterboard address select switch settings (Part 2 of 2)
Device Address
1
Switch Setting
