NT8D41BA Quad Serial Data Interface Paddle Board Page 689 of 906
Circuit Card Description and Installation
SW15 and SW16 must not be configured identically. Figure 161 on page 683
displays SW15 and SW16.
* To enable ports 1 and 2, set SW15 position 1 to ON. To enable ports 3 and 4, set SW16 position 1 to ON.
+
For each X, the setting for this switch makes no difference, because it is not used.
Table 217
NT8D41BA address switch settings
SW15 Port 1 Port 2 Switch settings
SW16 Port 3 Port 4 1* 2
+
3 4 5 6 7 8
Device
pair
addresses
0 1 E X off off off off off off
2 3 E X off off off off off on
4 5 E X off off off off on off
6 7 E X off off off off on on
8 9 E X off off off on off off
10 11 E X off off off on off on
12 13 E X off off off on on off
14 15 E X off off off on on on
