NT7D16 Data Access card Page 503 of 906
Circuit Card Description and Installation
Note: Warning Tone Denied (WTD) defaults if DTA is entered.
• If the DAC is used to call out through modem pooling, where the modem
pool consists of dumb modems connected to QMT8 SADM or QMT12
V.35 SADM, the DAC port should be configured with a secondary DN,
which has a single appearance.
• The Virtual keys must be assigned as shown in Table 164.
Table 164
Virtual key assignments
Feature key
Key number
Use SL-1 SL-100
Data DN 0 0 Required
Secondary DN 1 1 Required for manual
modem pooling
Call Transfer 2 — Required for manual
modem pooling
Auto Dial 3 2 Required for Hotline and VLL
Ring Again 4 6 Optional
Speed Call 5 3 Optional
Display 6 — Required
Make Set Busy 7 7 Optional
