NT5D11 and NT5D14 Lineside T1 Interface cards Page 209 of 906
Circuit Card Description and Installation
05 Off On Off On
06 Off On On Off
07 Off On On On
08 On Off Off Off
09 On Off Off On
10 On Off On Off
11 On Off On On
12 On On Off Off
13 On On Off On
14 On On On Off
15 On On On On
Table 82
Lineside T1 card – T1 Switch 2 (S2) dip switch settings (Part 1 of 2)
Dip Switch
Number Characteristic Selection
1 T1 framing On = D4
Off = ESF
2 T1 Coding On = AMI
Off = B8ZS
3–5 CPE or CSU distance See Table 83 on page 210
6 Line processing on T1 link failure On = On-hook
Off = Off-hook
Table 81
Lineside T1 card – XPEC address dip switch settings (Switch S1, positions 3 – 6)
(Part 2 of 2)
XPEC
Address
S1 Switch
Position 3 S1 Switch
Position 4 S1 Switch
Position 5 S1 Switch
Position 6
