Circuit Card Description and Installation
Power requirements
Table 180 provides the power requirements for the NT8D09 Analog Message
Waiting Line card.
Foreign and surge voltage protections
In-circuit protection against power line crosses or lightning is not provided on
the NT8D09 Analog Message Waiting line card.
Table 180
Power requirements
Voltage
(+/-)
Tolerance
Idle
current Active
current
Max
+ 12.0 V dc 0.36 V dc 48 mA 0 mA 48 mA
+ 8.0 V dc 0.40 V dc 150 mA 8 mA 280 mA
–48.0 V dc 2.00 V dc 48 mA 40 mA 688 mA
–48.0 V dc 5.00 V dc 0 mA 10 mA
(Note 1) 320 mA
86.0 V ac 5.00 V ac 0 mA 10 mA
(Note 2) 160 mA
–150.0 V dc 3.00 V dc 0 mA 2 mA 32 mA
Note 1: Each active ringing relay requires 10 mA of battery voltage.
Note 2: Reflects the current for ringing a single station set (or DN
telephone). There may be as many as five ringers on each line.
