Circuit Card Description and Installation
844
NTVQ01xx Media Card
Contents
This section contains information on the following topics:
Physical description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 839
Hardware architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 841
Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 843
Survivability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 843
Physical description
The Media Card replaces the ITG Pentium card and is available as an 8-port
or 32-port card.
You can install this card in slots 1 through 4 in the MG 1000S or slots 7
through 10 in the MG 1000S Expansion.
Note: Up to four Media Cards can be installed in each MG 1000S. Up to
four Media Cards can be installed in each MG 1000S Expansion.
An NTVQ01xx Media Card is shown in Figure 179.
