Page 674 of 906 NT8D41AA Serial Data Interface Paddle Board
553-3001-211 Standard 3.00 August 2005
DTE/DCE/Fiber mode
Each serial port can be configured to connect to a terminal (DTE equipment),
a modem (DCE equipment), or a Fiber Superloop Network card. Instructions
for setting the switches SW5, SW6, SW7, and SW8 are shown in Table 214
on
page 675 .
Table 213
SDI paddle board baud rate switch settings
Baud
rate
Port 1 – SW2 Port 2 – SW3
1 2 3 4 1 2 3 4
150 off off on on off off on on
300 off on off on off on off on
600 off off off on off off off on
1200 off on on off off on on off
2400 off off on off off off on off
4800 off on off off off on off off
9600 off off off off off off off off
