Technical Product Manual - DCT1900
Installation Instructions, Modular Cabinet – Cables
26-18 Install-DCT1900/R8/mw
© 2000-2005
26.14 CPU1/SDB Twisted Pair Sync Cable – TSRNB 101 48
The CPU/SDB twisted pair sync cable connects a CPU1 sync port to the SDB and is a part of the
installation set sync port NTMNB 101 107. The cable comprises two unshielded twisted pairs and
has a length of24” (see Figure 26–17).
Fig. 26–17 CPU1/SDB Twisted Pair Sync Cable TSRNB 101 48
1
2
3
4
5
6
7
8
X1
B
X2
GND (circuit)
A
GND (circuit) white
blue
white
orange
1
2
3
4
7
8 6
5
4
3
2
1
1 2 3 4
X1
X2
X2
2".2in
24 in " .4 in
X1
2 8
