Technical Product Manual - DCT1900
Installation Instructions, Modular Cabinet – CLU/SLU to Base Station Cabling
Install-DCT1900/R8/mw 21-9
© 2000-2005
Table 21-3 CLU to 66 Block Cabling
Connector Cable Pair-Pin Wire Color 25 Pair Connector Pin Signal Name
1 1-3 White 26 SC1-0 Circuit 1
1 1-2 Blue 1 SC1-1
1 2-7 White 27 SC0-0
1 2-6 Orange 2 SC0-1
1 3-5 White 28 EPP0
1 3-4 Green 3 EPP1
1 4-11 White 29 SC1-0 Circuit 2
1 4-10 Brown 4 SC1-1
1 5-15 White 30 SC0-0
1 5-14 Gray 5 SC0-1
1 6-13 Red 31 EPP0
1 6-12 Blue 6 EPP1
1 7-19 Red 32 SC1-0 Circuit 3
1 7-18 Orange 7 SC1-1
1 8-23 Red 33 SC0-0
1 8-22 Green 8 SC0-1
1 9-21 Red 34 EPP0
1 9-20 Brown 9 EPP1
1 10-27 Red 35 SC1-0 Circuit 4
1 10-26 Gray 10 SC1-1
1 11-31 Black 36 SC0-0
1 11-30 Blue 11 SC0-1
1 12-29 Black 37 EPP0
1 12-28 Orange 12 EPP1
