Technical Product Manual - DCT1900
Configuration Directions, Relation between Parts
6-2 Config-DCT1900/R8/mw
© 2000-2005
Power Supplies
Cables
Items Modular Cabinet Connects Remarks
Power Supply Unit Mains to Modular Cabinet. Powers system boards and a maximum of 24 Base
Stations.
Items Modular Cabinet
CLU/MDF Cable or CLU/MDF
Cable, Long 1 set per CLU or SLU A set consists of 2 cables with different cable clamp
positions. Normal version is 16 ft. Long version is 82 ft.
Connects 8 Base Stations to one 66 block.
CLU/MCCB Power Cable 1 per CLU or SLU Only when Base Stations are powered via the cabinet.
DTU/PBX Cable set (E1-
CCS or CAS) 1 per DTU A set consists of 2 cables with different cable clamp
positions.
DTU/PBX Cable Set
(T1-CCS or CAS) 1 per DTU One cable with two connectors for two circuits.
LTU Cable Set 1 per 3 LTUs Connects 24 extensions to one 66 block.
DLU Cable Set 1 per 2 DLUs Connects 48 extensions to one 66 block.
PC Cable 1 per system
Printer Cable 1 per system
CPU/SDB Cables 4 per CPU Part of the sync port installation set
SMS Cable 1 per Unit Comes with SMS system
Mains Power Cord 1 per Unit Comes with power supply kit
