Technical Product Manual - DCT1900

Installation Instructions, Central Processing Unit (CPU) – REX-BRD0004 or 2/ROFNB 157 19/2

5-6

Install-DCT1900/R8/mw

© 2000-2005

Fig. 5-3 FPGA Installation

Semi-circle

Beveled edge

Notched corner

Blocked corner

Arrow

Socket
