Technical Product Manual - DCT1900
Installation Instructions, Modular Cabinet Connection Board (MCCB) - ROANB 101 28
Install-DCT1900/R8/mw 17-3
© 2000-2005
Fig. 17–2 DTU Coax Cable Ground Strap Settings on MCCB
DTC In/Out Connectors
There are two rows of connectors for connection of the DTU-E1 coaxial cables. Each row has
connectors for up to 8 DTU-E1 input and output cables.
Due to the construction of the cabinet and the placement of the MCCB, two connectors on the
DTC In side and two connectors on the DTC Out side cannot be used. Refer to Fig. 17-3 and use
only the labelled connectors DTC 1-6.
DT C-O UT
R
S
R
S
R
S
R
S
R
S
R
S
R
S
R
S
DT C-O UT
D
T
C
1
D
T
C
2
D
T
C
3
D
T
C
4
D
T
C
5
D
T
C
6
Ground
Open
