Specifications
78 Powerware ® 9170 User's Guide S LTM-1344 B Uncontrolled Copy
Table 12. Isolation
Model 0650C Output
Neutral-to-Ground Bonding
±3% load regulation (under any line, load, or battery condition)
Neutral is carried through from input to output; a separate neutral-to-ground bond is
not required
Model 0650I Isolation, Including
Output Neutral-to-Ground
Bonding
True, separately-derived power source as defined by National Electrical Code
Article 250-5d, with output neutral bonded to ground. No direct connection between
input and output; neutral-to-ground bond is required; other local codes may take
precedence.
Table 13. Model Specifications
kVA Watts Input Current for
208/220/230/240V*
Output Current for
208/220/230/240V
Recommended
Input Service*
Heat Dissipation
Double-Conversion Mode
3 2100 17/16/15/15A 14.4/13.6/13.0/12.5A 25A 285W (0.98 kBTU/hr)
6 4200 31/29/28/27A 28.8/27.2/26.0/25.0A 40A 570W (1.95 kBTU/hr)
9 6300 46/44/42/41A 43.2/40.8/39.0/37.5A 60A 860W (2.93 kBTU/hr)
12 8400 62/59/56/53A 57.6/54.4/52.0/50.0A 80A 1145W (3.90 kBTU/hr)
15 10500 77/73/70/67A 72.0/68.0/65.0/62.5A 100A 1430W (4.88 kBTU/hr)
18 12600 93/87/84/80A 86.4/81.6/78.0/75.0A 125A 1720W (5.85 kBTU/hr)
Voltages Only Available with Split-Phase Modules
kVA Watts Input Current
for 200V*
Output Current for
100/200V, 110/220V, 120/240V
Recommended
Input Service*
Heat Dissipation
Double-Conversion Mode
3 2100 18A 30/15A, 27/14A, 25/12.5A 25A 285W (0.98 kBTU/hr)
6 4200 32A 60/30A, 54/28A, 50/25A 40A 570W (1.95 kBTU/hr)
9 6300 48A 90/45A, 81/42A, 75/37.5A 60A 860W (2.93 kBTU/hr)
12 8400 64A 120/60A, 108/56A, 100/50A 80A 1145W (3.90 kBTU/hr)
15 10500 80A 150/75A, 135/70A, 125/62A 100A 1430W (4.88 kBTU/hr)
18 12600 100A 180/90A, 162/84A, 150/75A 125A 1720W (5.85 kBTU/hr)
*For redundant power module operation (N+X), increase the input current rating by 2A for each additional redundant power
module.
