Electrical Installation
35
Powerware
®
9170 User's Guide
S
LTM-1344 B Uncontrolled Copy
Wiring Diagrams
Select wiring diagrams from Table 5 based upon the installation voltage
and whether your site has an external bypass switch.
Table 5. Wiring Diagrams for Non-Isolated Output
UPS Input
UPS Output
Output Wires
External
Wiring Diagrams
UPS Input
Voltage
UPS Output
Voltage
Output Wires
External
Bypass
Input
Output
System
100/200
110/220
120/208
100/200
110/220
120/208
L1 L2 N*
Yes
Figure 25a
Figure 26
Figure 28
120/208
120/240
127/220
120/208
120/240
127/220
L1, L2, N*
No
Figure 25a
Figure 26
Figure 29
208
220
208
220
L1 L2
Yes
Figure 25b
Figure 27
Figure 30
220
230
240
220
230
240
L1 ć L2
No
Figure 25b
Figure 27
Figure 31
220
230
220
230
L1 N
Yes
Figure 25b
Figure 27
Figure 32
230
240
230
240
L1 ć N
No
Figure 25b
Figure 27
Figure 33
*Split-phase power modules required.
UPS Input Wiring Connections
The Powerware 9170 UPS with split-phase power modules (model
ASY-0567, with blue labels on the front) is capable of supplying two
output voltages: 100/100 for 200, 110/110 for 220, 120/120 for 240,
120/120 for 208, or 127/127 for 220 Vac, as selected through the front
panel display. These modules produce two output voltages, typically
required in North America, South America, and Japan.
The Powerware 9170 UPS with universal power modules (model
ASY-0528, with white labels on the front) is capable of supplying a
single-phase output voltage: 208, 220, 230, or 240 Vac, as selected
through the front panel display. These modules produce a single output
voltage, typically required in Europe, the Middle East, Asia, and Africa.
