Operation
66 Powerware ® 9170 User's Guide S LTM-1344 B Uncontrolled Copy
In this example, the most recent inverter log (9 1 1) is being displayed.
If the unit is still running on inverter (battery power), an asterisk (*) is
displayed beside the date. 09/29" is the date of the Battery mode
operation: September 29. 13:56" means that Battery mode operation
started at 1:56 p.m. And 01:04" means the batteries supplied power for
1 hour and 4 minutes. For further information about the entry, hold
down . The bottom display line indicates a slot (drawer) number and a
reason code associated with the entry.
Table 8 contains a description of all inverter reason codes.
Table 8. Inverter Log Reason Codes
Reason
Code
Meaning Explanation
1 Line was Lost Input voltage was lost.
2 Battery Test Battery test initiated inverter operation.
3 Manual Operator initiated inverter operation.
Alarm Log
The alarm log is in menu 9, submenu 2. Move through the menu
structure by pressing the Menu button and pressing the
B
button to
move down to menu 9. Press , and press the
B
button to move down
to submenu 2. The display shows the most recent entry in the alarm log.
The log stores up to 16 entries, in chronological order. You can use the
Y
and
B
buttons to scroll up and down through the log entries. Each
entry shows the alarm code, the alarm date and time (in 24-hour
format), and the duration (in hours and minutes.)
A typical entry might look like this:
9 2 6 #0
Alarm Log 1
A 02/05 17:51 04:35
Slot Top ESC
