OPERATING ELEMENTS
37
Foot brake pedal
100183-10
The footbrake pedal
b
is located in front of the right footrest.
The footbrake pedal operates the rear brake.
Side stand
500034-10
The side stand
b
is coupled with the safety electric starter system - see the riding instruc-
tions.
Possible states
•
Side stand folded out
ದbThe vehicle can be supported on the side stand. The safety
electric starter system is active.
•
Side stand folded in
ದbThis position is mandatory for all journeys. The safety electric
starter system is inactive.
