TECHNICAL DATA - ENGINE TIGHTENING TORQUES
140
Screw, shift drum locating
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, shift lever
M6
10
bNm (7.4blbfbft)
Loctite
®
222
Screw, timing chain tensioning rail
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, starter motor
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, stator bracket
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, thermostat housing
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, valve cover
M6
10
bNm (7.4blbfbft)
ದ
Screw, water pump cover
M6
10
bNm (7.4blbfbft)
ದ
Screw, water pump wheel
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, cylinder
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Screw, cylinder head
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Plug, vacuum connection
M6
10
bNm (7.4blbfbft)
Loctite
®
243™
Stud, exhaust flange
M8
10
bNm (7.4blbfbft)
Loctite
®
243™
Plug, crankshaft location
M8
20
bNm (14.8blbfbft)
ದ
Screw, unlocking of timing chain ten-
sioner
M10x1
10
bNm (7.4blbfbft)
ದ
Plug, drain hole of water pump
M10x1
15
bNm (11.1blbfbft)
ದ
Plug, oil bore for oil radiator
M10x1
15
bNm (11.1blbfbft)
ದ
Plug, oil bore
M10x1
15
bNm (11.1blbfbft)
Loctite
®
243™
