TECHNICAL DATA - CHASSIS TIGHTENING TORQUES
148
7(&+1,&$/ '$7$ &+$66,6 7,*+7(1,1* 72548(6
Screw, combination instrument 1 bNm (0.7blbfbft) ದ
Screw, combination instrument holder 1 bNm (0.7blbfbft) ದ
Screw, side stand switch M4 2 bNm (1.5blbfbft) Loctite ® 243™
Spoke nipple, front wheel (690 bSUPER-
MOTO)
M4,5 5 bNm (3.7blbfbft) ದ
Remaining screws, chassis M5 4 bNm (3blbfbft) ದ
Screw, exhaust heat shield M5 5 bNm (3.7blbfbft) Loctite ® 243™
Screw, pressure regulator M5 4 bNm (3blbfbft) ದ
Screw, footbrake pedal foothold M5 6 bNm (4.4blbfbft) Loctite ® 243™
Screw, plastic clamp of brake line on
fork leg M5 2 bNm (1.5blbfbft) ದ
Screw, fuel pump M5 4 bNm (3blbfbft) ದ
Screw, fuel level indicator M5 3 bNm (2.2blbfbft) ದ
Screw, side cover M5 2 bNm (1.5blbfbft) ದ
Screw, seat lock M5 3 bNm (2.2blbfbft) Loctite ® 222
Screw, starter cable on starter M5 3 bNm (2.2blbfbft) ದ
Spoke nipple, rear wheel (690 bSUPER-
MOTO)
M5 5 bNm (3.7blbfbft) ದ
Remaining nuts, chassis M6 15 bNm (11.1blbfbft) ದ
Remaining screws on fuel tank M6 6 bNm (4.4blbfbft) ದ
Remaining screws, chassis M6 10 bNm (7.4blbfbft) ದ
Screw, compensating tank of rear brake M6 5 bNm (3.7blbfbft) ದ
Screw, battery holder M6 3 bNm (2.2blbfbft) ದ
Screw, rear brake disc (690 bSUPER-
MOTO)
M6 14 bNm (10.3blbfbft) Loctite ® 243™
