OPERATING ELEMENTS
31
Combination instrument -
bTRIPbF display
700123-01
When the fuel level reaches the reserve mark, the display automatically changes to
bTRIPbF
and begins to count from
b0.0, regardless of which display mode was previously active.
Info
Parallel to the
bTRIPbF display, the fuel warning light begins to light up.
Combination instrument - coolant temperature indicator
700124-01
The temperature indicator in the display consists of 12 bars. The more bars that light up,
the hotter the coolant. When the top bar lights up, all bars begin to flash simultaneously
and the temperature warning lamp begins to light up.
Possible states
•
Engine cold
ದbup to four bars.
•
Engine at normal operating termperature
ದbfrom five to eleven bars.
•
Engine hot
ದball twelve bars flash.
