OPERATING ELEMENTS
24
Combination instrument
700116-01
The combination instrument is attached in fromt of the handlebar.
The combination instrument is divided into 4 function areas.
bFunction buttons
Tachometer
Indicator lights
Display
Combination instrument - function buttons
700117-01
Press the
bMODEbbuttonb
to change the display mode.
Possible display modes are total distance covered (ODO), tripmaster
b1b(TRIPb1) and tripmas-
ter
b2b(TRIPb2).
Press the
bSETbbuttonb
to reset tripmaster
b1b(TRIPb1) and tripmasterb2b(TRIPb2) tob0.0.
Button
b
has no function.
