TECHNICAL DATA - ENGINE TIGHTENING TORQUES
139
7(&+1,&$/ '$7$ (1*,1( 7,*+7(1,1* 72548(6
Plug, oil bore self-tapping 9 bNm (6.6blbfbft) Loctite ® 243™
Screw, membrane fixation M3 2.5 bNm (1.84blbfbft) Loctite ® 243™
Oil jet, conrod lubrication M4 2 bNm (1.5blbfbft) Loctite ® 243™
Hose clamp, intake flange M4 1.5 bNm (1.11blbfbft) ದ
Screw, cover plate for oil return line M5 6 bNm (4.4blbfbft) ದ
Screw, breather cover on valve cover M5 3 bNm (2.2blbfbft) Loctite ® 243™
Screw, gear sensor M5 5 bNm (3.7blbfbft) Loctite ® 243™
Screw, clutch spring M5 6 bNm (4.4blbfbft) ದ
Locking screw for bearing M5 6 bNm (4.4blbfbft) Loctite ® 648™
Screw, oil filter cover M5 6 bNm (4.4blbfbft) ದ
Screw, oil pump cover M5 6 bNm (4.4blbfbft) Loctite ® 243™
Oil jet, piston cooling M6x0.75 4 bNm (3blbfbft) Loctite ® 243™
Screw, locking lever M6 10 bNm (7.4blbfbft) Loctite ® 243™
Screw, Autodecompression M6 3… 4 bNm (2.2… 3blbfbft) Loctite ® 243™
Screw, axial lock of camshaft M6 10 bNm (7.4blbfbft) Loctite ® 243™
Screw, timing chain guide rail M6 10 bNm (7.4blbfbft) Loctite ® 243™
Screw generator cover M6 10 bNm (7.4blbfbft) ದ
Screw in generator cover (chain shaft
through-hole) M6 10 bNm (7.4blbfbft) Loctite ® 243™
Screw, ignition pulse generator M6 10 bNm (7.4blbfbft) Loctite ® 243™
Screw, rocker arm shaft M6 12 bNm (8.9blbfbft) ದ
Screw, clutch cover M6 10 bNm (7.4blbfbft) ದ
Screw, clutch slave cylinder M6x20 10 bNm (7.4blbfbft) Loctite ® 243™
Screw, clutch slave cylinder M6x35 10 bNm (7.4blbfbft) ದ
Screw, engine housing M6 10 bNm (7.4blbfbft) ದ
