TECHNICAL DATA - CHASSIS TIGHTENING TORQUES
150
Screw, front brake disc (690 bSUPER-
MOTO bR)
M8 30 bNm (22.1blbfbft) Loctite ® 243™
Screw, spring holder on side stand
bracket M8 25 bNm (18.4blbfbft) Loctite ® 243™
Screw, rear footrest clamp M8 25 bNm (18.4blbfbft) ದ
Screw, rear footrest bracket M8 25 bNm (18.4blbfbft) Loctite ® 243™
Screw, top triple clamp M8 12 bNm (8.9blbfbft) ದ
Screw, bottom triple clamp M8 15 bNm (11.1blbfbft) ದ
Screw, fork stub M8 15 bNm (11.1blbfbft) ದ
Screw, steering stem M8 20 bNm (14.8blbfbft) ದ
Screw, handrail M8 6 bNm (4.4blbfbft) ದ
Screw, fuel tank bracket M8 15 bNm (11.1blbfbft) ದ
Screw, manifold on main silencer M8 25 bNm (18.4blbfbft) Copper paste
Screw, handlebar clamp M8 20 bNm (14.8blbfbft) ದ
Screw, upper subframe M8 35 bNm (25.8blbfbft) Loctite ® 243™
Screw, side stand bracket M8 25 bNm (18.4blbfbft) Loctite ® 243™
Screw, linkage bracket, front engine
bracket M8 25 bNm (18.4blbfbft) Loctite ® 243™
Screw, ignition lock M8 Loctite ® 243™
Screw, front brake caliper M10x1.25 45 bNm (33.2blbfbft) Loctite ® 243™
Screw, lower subframe M10x1.25 45 bNm (33.2blbfbft) Loctite ® 243™
Engine carrying screw M10 45 bNm (33.2blbfbft) Loctite ® 243™
Remaining nuts, chassis M10 50 bNm (36.9blbfbft) ದ
Remaining screws, chassis M10 45 bNm (33.2blbfbft) ದ
Screw, top shock absorber M10 45 bNm (33.2blbfbft) Loctite ® 243™
