Maintenance work on chassis and engine – KTM Supermoto 690 User Manual
Page 118
MAINTENANCE WORK ON CHASSIS AND ENGINE
116
Danger
Danger of poisoning
ಘExhaust gases are poisonous and can result in
unconsciousness and/or death.
ದ
When running the engine, always make sure there is sufficient ventilation,
and do not start or run the engine in a closed space.
ದ
Start the engine and let it run idle. Move the handlebar to and fro over the entire steer-
ing range.
The idle speed must not change.
»
If the idle speed changes:
ದ
Adjust the play in the gas Bowden cable.
b
x
(
P. 116)
Adjusting play in gas Bowden cable
b
x
100195-10
ದ
Move the handlebar to the straight-ahead position.
ದ
Loosen the lock nut
b
.
ದ
Adjust the play in the gas Bowden cable by turning the adjusting screw
b
.
Specification
Play in gas Bowden cable
3… 5
bmm (0.12… 0.2bin)
ದ
Tighten the lock nut
b
.
