TECHNICAL DATA - FORK
145
7(&+1,&$/ '$7$ )25.
Fork part number (690 bSUPERMOTO) 14.18.7D.07
Fork part number (690 bSUPERMOTObR) 14.18.7D.08
Fork WP bSuspension Up Side Down 4860 ROMA
Compression damping (690 bSUPERMOTObR)
Comfort 20 bclicks
Standard 15 bclicks
Sport 10 bclicks
full payload 10 bclicks
Rebound damping
Comfort 20 bclicks
Standard 15 bclicks
Sport 10 bclicks
full payload 10 bclicks
Spring length with preload spacer(s) 430 bmm (16.93bin)
Spring rate
Weight of rider: 65… 75 bkg (143… 165blb.) 4.8 bN/mm (27.4blb/in)
Weight of rider: 75… 85 bkg (165… 187blb.) 5.2 bN/mm (29.7blb/in)
Weight of rider: 85… 95 bkg (187… 209blb.) 5.6 bN/mm (32blb/in)
Air chamber length 100 +30
෥20 bmm (3.94 +1.18
෥0.79 bin)
Fork length 850 bmm (33.46bin)
Fork oil ( P. 153) SAE 5
