MAINTENANCE WORK ON CHASSIS AND ENGINE
121
700104-01
ದ
Remove screws
b
. Remove oil filter cover
b
with O-ring.
ದ
Pull the oil filter insert
b
out of the oil filter casing.
Circlip pliers reverse (51012011000)
ದ
Completely drain the engine oil.
ದ
Thoroughly clean parts and sealing area.
Mounting oil filter
b
x
700105-01
ದ
Check parts for damage and wear. Replace damaged or worn parts.
ದ
Insert oil filter
b
and
b
.
ದ
Oil the O-rings of the oil filter cover. Refit the oil filter cover
b
and
b
.
ದ
Mount and tighten screws.
Specification
Screw, oil filter cover
M5
6
bNm (4.4blbfbft)
Cleaning oil screens
b
x
Warning
Danger of scalding
ಘEngine oil and gear oil get very hot when the motocycle is driven.
ದ
Wear suitable protective clothing and gloves. If you scald yourself, hold the affected area under cold water immediately.
