TECHNICAL DATA - SHOCK ABSORBER
146
7(&+1,&$/ '$7$ 6+2&. $%625%(5
Shock absorber part number (690 bSUPERMOTO) 15.18.9D.07
Shock absorber part number (690 bSUPERMOTObR) 15.18.7D.08
Shock absorber WP bSuspensionb4618 with ProತLever deflector
Compression damping, high-speed (690 bSUPERMOTObR)
Comfort 2 bturns
Standard 1.5 bturns
Sport 1 bturn
full payload 1 bturn
Compression damping, low-speed (690 bSUPERMOTObR)
Comfort 20 bclicks
Standard 15 bclicks
Sport 10 bclicks
full payload 10 bclicks
Rebound damping
Comfort 20 bclicks
Standard 15 bclicks
Sport 10 bclicks
full payload 10 bclicks
Spring preload 12 bmm (0.47bin)
Spring rate
Weight of rider: 65… 75 bkg (143… 165blb.) 60 bN/mm (343blb/in)
Weight of rider: 75… 85 bkg (165… 187blb.) 65 bN/mm (371blb/in)
Weight of rider: 85… 95 bkg (187… 209blb.) 70 bN/mm (400blb/in)
Spring length 220 bmm (8.66bin)
