TECHNICAL DATA - CHASSIS
143
Rear 2.2 bbar (32bpsi)
Rear wheel gearing 16:40
Chain 5/8 bxb1/4” Xತring
Steering head angle 63.5°
Wheelbase 1,472±15 bmm (57.95±0.59bin)
Seat height unloaded 880 bmm (34.65bin)
Ground clearance unloaded 245 bmm (9.65bin)
Weight without fuel 154 bkg (340blb.)
Maximum permissible front axle load 150 bkg (331blb.)
Maximum permissible rear axle load 200 bkg (441blb.)
Maximum permissible overall weight 350 bkg (772blb.)
Battery YTZ10S Battery voltage: 12 bV
Nominal capacity: 8.6 bAh
maintenance-free
Fuse 58011109130 30 bA
Fuse 75011088015 15 bA
Fuse 75011088010 10 bA
Lighting equipment
Headlight H4/P43t 12 bV
60/55 bW
Parking light W2,1x9,5d 12 bV
5 bW
Instrument lights and indicator lamps LED
