MAINTENANCE WORK ON CHASSIS AND ENGINE
100
100156-10
ದ
Pull the bulb holder of the parking light
b
out of the headlight housing.
ದ
Pull the plug-in connector
b
off the headlight.
ದ
Place the headlight mask to one side.
Refitting the headlight mask with the headlight
100156-11
ದ
Connect the plug-in connector
b
to the headlight.
ದ
Insert the bulb holder of the parking light
b
into the headlight housing.
