Digital Multi Effects (DME)
DVS-9000/9000SF
3-704-674-01 (1)
For details of this menu, see “Global Effect Operations” in Chapter 11
(Volume 2).
The following types of global effects are available.
• Combiner
• Brick
• Shadow
Combiner
When multiple channels are selected on one keyer or for one transition, the
Combiner automatically combines the selected images. Up to three channels
can be combined.
You can also control the way in which the combination is carried out, as a mix
or an overlap with priority set automatically. For a mix, you can control the
relative amounts of each channel.
Combination of channel 1 (Ch1) and channel 2 (Ch2)
Ch1
Ch2
Ch1
Ch3
Ch4
Ch3
Ch4
1
2
1
2
3
4
3
4
Combiner
