Basic Procedure for Wipe Settings
Chapter 5
Wipes
DVS-9000/9000SF
3-704-674-01 (1)
2
In the group, select the slit direction.
H: Create slits in the horizontal direction.
V: Create slits in the vertical direction.
3
Set the following parameters.
a) See page 54.
Applying modulation to the wipe pattern (Modulation)
You can apply modulation independently to the main pattern and sub pattern.
Use the following procedure.
1
In the M/E-1>Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
Depending on the desired effect, in the group select one of
the following.
H: Modulate the pattern, applying waviness in the horizontal direction to
edges.
V: Modulate the pattern, applying waviness in the vertical direction to
edges.
Fringe: Modulate the pattern, applying waviness in the radial direction to
edges.
3
Set the following parameters.
.
a) See page 55.
b) See page 55.
Knob Parameter Adjustment Setting values
1 Width Width of the slits 1 to 128 (integer)
2 H Offset Spacing in the horizontal direction − 100.00 to + 100.00 a)
3 V Offset Spacing in the vertical direction − 100.00 to + 100.00 a)
Knob Parameter Adjustment Setting values
1 Amplitude Amplitude of modulation 0.00 to 100.00
2 Frequency Frequency of modulation 0.00 to 100.00
3 Speed Speed of waves −
100.00 to +100.00
a)
4 Shape Form of the modulation 1 to 3 b)
