Basic Procedure for Wipe Settings
Chapter 5
Wipes
DVS-9000/9000SF
3-704-674-01 (1)
The following sections show examples of modifying the main pattern.
Specifying the wipe direction (Direction)
You can specify the wipe direction (normal/reverse).
To specify the wipe direction in a menu
Use the following procedure.
1
In the M/E-1> Wipe menu, select HF4 ‘Edge/Direction.’
The Edge/Direction menu appears.
2
In the group, specify the wipe direction.
Normal: regular direction
Normal/Reverse: alternate between regular and reverse for each transition
Reverse: reverse direction to normal
To specify the wipe direction with a button in the transition control
block
In the transition control block of each of the M/E-1 and PGM/PST banks, press
the following direction selection buttons.
NORM: Normal
NORM/REV: Normal/reverse
REV: Reverse
Splitting the wipe pattern
Use the following procedure.
1
In the M/E-1 > Wipe menu, select HF4 ‘Edge/Direction.’
The Edge/Direction menu appears.
2
Presss [Split], turning it on.
3
Set the following parameters.
Modifying the wipe pattern edge
Use the following procedure.
Knob Parameter Adjustment Setting values
1 Split No. Number of splits 1 to 4 (integer)
2 Spacing Spacing between adjacent
patterns 0.00 to 100.00
