Key Setting Operations Using Menus
DVS-9000/9000SF
3-704-674-01 (1)
The Main Mask menu appears.
2
In the group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
3
In the group, select the mask source.
Box: signal from the dedicated box generator
Pattern: signal from the dedicated pattern generator
4
Set the mask source parameters.
• When a box is selected
• When a pattern is selected
a) The pattern is the same as a standard wipe. (See the appendix “Wipe Pattern List” (Volume
2).)
To select the pattern, display the Mask Ptn Select menu by pressing the
[Mask Ptn Select] button in the Main Mask menu. After selecting one of
the patterns (standard wipe patterns 1 to 24) displayed in the Mask Ptn
Select menu, you can adjust the following parameters.
Knob Parameter Adjustment Setting values
1 Top Top position
−
100.00 to +100.00
2 Left Left position
−
100.00 to +100.00
3 Right Right position
−
100.00 to +100.00
4 Bottom Bottom position − 100.00 to +100.00
5 Soft Box softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
5 Pattern Pattern number
1 to 24
a)
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
